| 上料管道
Feeding method | 後上料
/Rear feeding |
| 鋸切長度
Max.cutting length | 3180mm |
| 鋸切寬度
Max.cutting width | 3300mm |
| 鋸片最大高度
Max.height of blade | 100mm智慧升降
100mm intelligent lifting |
| 主鋸片
Main saw blade | 400×4.4/3.2×75×72Tx15/105可選450×4.4/3.2x75XT2T×15/105 |
| 槽鋸片
Scoring saw blade | 160×5.3/3.2×45×24T |
| 鋸座前進速度
Forward speed of saw carriage | 5-100m/min |
| 鋸座回程速度
Backward speed of saw carriage | 0-100m/min |
| 機械手前進速度
Forward speed of mechanical grippers | 0-100m/min |
| 機械手回程速度
Backward speed of mechanical grippers | 0-100m/min |
| 側壓裝置
Side pressure device | 氣動雙側壓輪
Pneumatic double side pressure wheels |
| 主鋸軸馬達功率
Motor power of main saw shaft | 22KW |
| 槽鋸軸馬達功率
Motor power of scoring saw shaft | 2.2KW |
| 鋸車伺服電機
Saw carriage servo motor | 1.8KW |
| 送料軸電機
Feeding shaft motor | 1.8KW |
| 側送料軸電機
Sid feedingshaft motor | - |
| 機械手數量
Mechanical gripper' s quantity | 10PCS |
| 氣浮臺高壓風機
High pressure blower of airfloating table | 2.2KW |
| 後上料平臺尺寸
Rear feeding table' s dimension | 3800x2200x600mm |
| 包裝尺寸
Packing size | 5400x1420x2200mm
5900x920x1000mm
3800x2050x1000mm |
| 機械占地面積
Floor area | 8100x5400x2220mm |
| Weight
Weight | 10500kg |
| 最小板材尺寸
Minimum cutting size | 50x30mm |
| 總功率
Total power | 39KW |
